Machine tools and equipment / Metalworking machine tools / Electrical discharge machines (EDM) / CNC-EB EDM / CNC-EB EDM CNC-EB540L
JSedm

CNC-EB EDM CNC-EB540L

Серия: EB
Working table size 800mm x 450mm
X/Y-Axis travel 500mm / 400mm
Z-Axis travel 350mm
Max. weight of workpiece 1350kg
Operating current 60A

Цена и условия

6 517 280 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Machine unit

Die-sink EDM Machine design Movable table
Working table size 800mm x 450mm
Work tank inner size 1170mm x 700mm x 430mm
X/Y-Axis travel 500mm / 400mm
Z-Axis travel 350mm
Max. weight of workpiece 1350kg
Distance between table surface and electrode plate 135mm – 485mm
Max. electrode weight 150kg

Dielectric fluid unit

Tank capacity 520L
Filter type Paper filter / 2pcs

Pulse generator

Operating current 60A
Total power input 7kVA
Max.material removal rate 400mm³/min
Electrode wear rate 0.12%

Accuracy

Best surface roughness 0.2μm/Ra

CNC

Software Windows based
EDM system CNC
Controlled axis X-axis / Y-axis / Z-axis
Setting limits 0.001mm
Display 15″ / TFT LCD

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 1950kg
Overall length 3800mm
Overall width 2000mm
Overall height 2300mm

Комплектация

Auto. Tool change
C axis
Chiller
EROWA clamping tool
Filter
Количество: 2 pcs
Fire extinguisher
Количество: 1 pcs
Full-automatic
+GF+ System 3R Clamping tools
Magnetic chuck
Tools box
Количество: 1 pcs
Лампа освещения рабочей зоны
Количество: 1 pcs
