Machine tools and equipment / Metalworking machine tools / Electrical discharge machines (EDM) / CNC-EB EDM / CNC-EB EDM CNC-EB433
JSedm

CNC-EB EDM CNC-EB433

Серия: EB
Working table size 600mm x 350mm
X/Y-Axis travel 400mm / 300mm
Z-Axis travel 300mm
Max. weight of workpiece 500kg
Operating current 60A

Цена и условия

4 856 352 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Machine unit

Die-sink EDM Machine design Movable table
Working table size 600mm x 350mm
Work tank inner size 900mm x 520mm x 385mm
X/Y-Axis travel 400mm / 300mm
Z-Axis travel 300mm
Max. weight of workpiece 500kg
Distance between table surface and electrode plate 350mm – 850mm
Max. electrode weight 100kg

Dielectric fluid unit

Tank capacity 300L
Filter type Paper filter / 2pcs

Pulse generator

Operating current 60A
Total power input 7kVA
Max.material removal rate 400mm³/min
Electrode wear rate 0.12%

Accuracy

Best surface roughness 0.2μm/Ra

CNC

Software Windows based
EDM system CNC
Controlled axis X-axis / Y-axis / Z-axis
Setting limits 0.001mm
Display 15″ / TFT LCD

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 1750kg
Overall length 1700mm
Overall width 1600mm
Overall height 2350mm

Комплектация

Auto. Tool change
C axis
Chiller
EROWA clamping tool
Filter
Количество: 2 pcs
Fire extinguisher
Количество: 1 pcs
Full-automatic
+GF+ System 3R Clamping tools
Magnetic chuck
Tools box
Количество: 1 pcs
Лампа освещения рабочей зоны
Количество: 1 pcs
