SMTCL

Horizontal CNC Lathe iT 35

Серия: iT

Max. swing diameter over bed 580mm

Max Cutting Diameter 360mm

Max. swing over cross slide: 360mm

Processing length 350mm

Цена и условия

Цена по запросу

Характеристики

Capability

Max. swing diameter over bed 580mm

Max Cutting Diameter 360mm

Max. swing over cross slide: 360mm

Processing length 350mm

Headstock

Spindle speeds range 4000rpm

Spindle taper Metric #120

Lathe Spindle Nose A2-6

Spindle bore diameter 65mm

Bar Size 50mm

Spindle Bearing Inner Diameter 100mm

Spindle torque 158N⋅m / 215N⋅m

Spindle motor power 11kW / 15kW

Lathe chuck

Chuck size 8″

Clamping type Hydraulic

Feeds

X-Axis travel 200mm

Z-Axis travel 350mm

Rapid traverse 30000mm/min / 30000mm/min

Carriage

Tool post Lathe turret

Number of stations 8pcs

Indexing time 1.6sec.

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3300kg

Overall length 2330mm

Overall width 1675mm

Overall height 1760mm
