SMTCL

Horizontal CNC Lathe iT 50

Серия: iT

Max. swing diameter over bed 580mm

Max. swing over cross slide: 320mm

Processing length 500mm

Цена и условия

Цена по запросу

Характеристики

Capability

Max. swing diameter over bed 580mm

Max Cutting Diameter 500mm

Max. swing over cross slide: 320mm

Processing length 500mm

Headstock

Spindle speeds range 3500rpm

Spindle taper Metric #120

Lathe Spindle Nose A2-8

Spindle bore diameter 65mm

Bar Size 65mm

Spindle Bearing Inner Diameter 120mm

Spindle torque 243N⋅m / 300N⋅m

Spindle motor power 15kW / 18.5kW

Lathe chuck

Chuck size 10″

Clamping type Hydraulic

Feeds

X-Axis travel 260mm

Z-Axis travel 505mm

Rapid traverse 24000mm/min / 24000mm/min

Carriage

Tool post Lathe turret

Number of stations 8pcs

Indexing time 1.6sec.

Tailstock

Max. travel of tailstock quill 400mm

Taper MT5

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3700kg

Overall length 2550mm

Overall width 1675mm

Overall height 1820mm
