SMTCL

Horizontal CNC Lathe iT 35L

Серия: iT

Max. swing diameter over bed 580mm

Max Cutting Diameter 360mm

Max. swing over cross slide: 330mm

Processing length 500mm

Цена и условия

4 817 365 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Capability

Max. swing diameter over bed 580mm

Max Cutting Diameter 360mm

Max. swing over cross slide: 330mm

Processing length 500mm

Headstock

Spindle speeds range 4000rpm

Spindle taper Metric #120

Lathe Spindle Nose A2-6

Spindle bore diameter 65mm

Bar Size 50mm

Spindle Bearing Inner Diameter 100mm

Spindle torque 158N⋅m / 215N⋅m

Spindle motor power 11kW / 15kW

Lathe chuck

Chuck size 8″

Clamping type Hydraulic

Feeds

X-Axis travel 200mm

Z-Axis travel 510mm

Rapid traverse 30000mm/min / 30000mm/min

Carriage

Tool post Lathe turret

Number of stations 8pcs

Indexing time 1.6sec.

Tailstock

Max. travel of tailstock quill 400mm

Taper MT5

CNC

Model Fanuc

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3600kg

Overall length 2550mm

Overall width 1675mm

Overall height 1760mm
