Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / Lathe machining center DT-40
DMTG

Lathe machining center DT-40

Серия: DT
Max. swing diameter over bed 580mm

Основная конфигурация

Processing length
585mm
1080mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe

Capability

Max. swing diameter over bed 580mm
Processing length
585mm
1080mm

Main spindle

Spindle drive
Belt drive
Belt drive
Spindle speeds range
35rpm — 4000rpm
35rpm — 3500rpm
Lathe Spindle Nose
A2-6
A2-8
Spindle bore diameter
70mm
87mm
Bar Size
51mm
73mm

Back spindle

Spindle motor power
11kW / 15kW

Feeds

X-Axis travel 215mm
Max. speed of traverse feeds 9000mm/min / 12000mm/min
Rapid traverse 30000mm/min / 30000mm/min
Z-Axis travel
600mm
1100mm
Positioning accuracy
0.005mm / 0.007mm / 44'' / 44'
0.005mm / 0.008mm / 44'' / 44'
Repeatability accuracy
0.003mm / 0.004mm / 18''
0.003mm / 0.005mm / 18''

Carriage

Tool post Lathe turret

Tools

Tooling Static tooling
Tools quantity 12pcs
Tool shank 25mm x 25mm

Tailstock

Max. travel of tailstock quill 140mm
Tailstock quill diameter 85mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC
