Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / Turning center DT-40H
DMTG

Turning center DT-40H

Серия: DT
Max. swing diameter over bed 580mm

Основная конфигурация

Processing length
555mm
1055mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe

Capability

Max. swing diameter over bed 580mm
Processing length
555mm
1055mm

Main spindle

Spindle drive
Belt drive
Belt drive
Spindle speeds range
35rpm — 4000rpm
35rpm — 3500rpm
Lathe Spindle Nose
A2-6
A2-8
Spindle bore diameter
70mm
87mm
Bar Size
51mm
73mm
Spindle torque
105N⋅m / 140N⋅m
105N⋅m / 140N⋅m

Back spindle

Spindle motor power
11kW / 15kW
11kW / 15kW

Feeds

X-Axis travel 215mm
X-axis transmission type Ball screw / Ø 32mm
Z-axis transmission type Ball screw / Ø 40mm
Max. speed of traverse feeds 9000mm/min / 12000mm/min
Rapid traverse 30000mm/min / 30000mm/min
Z-Axis travel
600mm
1080mm
Positioning accuracy
0.011mm / 0.018mm / 44'' / 44'
0.005mm / 0.008mm / 31'' / 31'
Repeatability accuracy
0.004mm / 0.007mm / 18''
0.003mm / 0.005mm / 113''

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling
Tools quantity 12pcs
Tool shank 25mm x 25mm
Tool shank diameter 40mm
Live tooling speed 5000rpm
Max. drilling diameter 22mm
Tapping capacity M16 x 2 / M30 × 1,5
Milling capacity 25mm x 15mm

Tailstock

Tailstock Hydraulic
Max. travel of tailstock quill 140mm
Tailstock quill diameter 85mm
Tailstock stroke
900mm
960mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC
