Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / Turning center DT-30H
DMTG

Turning center DT-30H

Серия: DT
Max. swing diameter over bed 480mm
Processing length 300mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe

Capability

Max. swing diameter over bed 480mm
Processing length 300mm

Main spindle

Spindle drive
Belt drive
Belt drive
Spindle speeds range
5000rpm
4500rpm
Lathe Spindle Nose
A2-5
A2-6
Spindle bore diameter
63mm
63mm
Bar Size
45mm
47mm

Back spindle

Spindle motor power
7.5kW / 11kW
7.5kW / 11kW

Feeds

X-Axis travel 165mm
Z-Axis travel 300mm
Rapid traverse 30000mm/min / 30000mm/min
Positioning accuracy 0.005mm / 0.005mm / 44'' / 44'
Repeatability accuracy 0.003mm / 0.003mm / 18''

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling
Tools quantity 12pcs
Tool shank 20mm x 20mm

Tailstock

Max. travel of tailstock quill 120mm
Tailstock quill diameter 70mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 4000kg
Overall length 2360mm
Overall width 1721mm
Overall height 1835mm

Периферия

Tool measuring system

TS27R
TS27R
