Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / Turning center CTXY52
STS

Turning center CTXY52

Серия: CTX
Max. swing diameter over bed 700mm
Max. swing over cross slide: 350mm
Spindle speeds range 3500rpm
Spindle motor power 11kW / 15kW

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30° / Combo lathe mill
Y-axis Presence

Capability

Max. swing diameter over bed 700mm
Max. swing over cross slide: 350mm
Processing length 520mm

Main spindle

Spindle drive Belt drive
Spindle speeds range 3500rpm
Lathe Spindle Nose A2-6
Spindle bore diameter 62mm
Bar Size 51mm
Spindle torque 73N⋅m / 100N⋅m
Spindle motor power 11kW / 15kW

Feeds

X-Axis travel 200mm
X-axis transmission type 32mm
Z-Axis travel 550mm
Z-axis transmission type 40mm
Y-Axis travel 45mm
Rapid traverse 25000mm/min / 25000mm/min / 25000mm/min
Repeatability accuracy 0.002mm / 0.002mm / 0.002mm

Feed motor

Power of feed motors 1.8kW / 1.8kW / 1.8kW / 5.32kW

Carriage

Tool post Lathe turret

Tools

Tooling Live tooling
Tools quantity 12pcs
Motor power 2.9kW
Live tooling speed 3000rpm
Max. drilling diameter 16mm
Tapping capacity M12

Tailstock

Tailstock Hydraulic
Morse cone MT5
Tailstock stroke 500mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 4500kg
Overall length 3030mm
Overall width 2045mm
Overall height 2050mm
