Machine tools and equipment / Metalworking machine tools / CNC machining centers / CNC Turning Centers / Turning center HTXY46
STS

Turning center HTXY46

Серия: CTX
Max. swing diameter over bed 480mm
Max. swing over cross slide: 300mm
Spindle speeds range 5000rpm
Spindle motor power 11.6kW / 18.5kW

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30° / Combo lathe mill

Capability

Max. swing diameter over bed 480mm
Max. swing over cross slide: 300mm
Processing length 340mm

Main spindle

Spindle speeds range 5000rpm
Lathe Spindle Nose A2-5
Spindle bore diameter 56mm
Bar Size 45mm
Spindle torque 37N⋅m / 84N⋅m
Spindle motor power 11.6kW / 18.5kW

Feeds

X-Axis travel 220mm
X-axis transmission type 40mm
Z-Axis travel 350mm
Z-axis transmission type 40mm
Y-Axis travel 40mm
Rapid traverse 20000mm/min / 20000mm/min / 20000mm/min
Repeatability accuracy 0.002mm / 0.002mm / 0.002mm

Feed motor

Power of feed motors 1.8kW / 1.8kW / 1.8kW / 5.832kW

Carriage

Tool post Lathe turret
Tool сhanging time (Adjacent/Farthest) 2sec.

Tools

Tooling Live tooling
Tools quantity 12pcs
Motor power 2.9kW
Live tooling speed 4000rpm
Max. drilling diameter 16mm
Tapping capacity M12

Tailstock

Tailstock Hydraulic
Tailstock stroke 400mm

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 4700kg
Overall length 3355mm
Overall width 1920mm
Overall height 2156mm
