Machine tools and equipment / Metalworking machine tools / Drilling machines / Vertical drilling machines / Vertical drilling machine B16H
TOPTECH

Vertical drilling machine B16H

Серия: B Pro
Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine
Max. drilling diameter 13mm
Working table size 230mm x 245mm
Table stroke 495mm
Spindle speeds range 450rpm — 3500rpm
Spindle taper MT2
Travel of spindle quill 65mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine
Design drilling machine

Capability

Max. drilling diameter 13mm

Working table

Working table size 230mm x 245mm
T-slots 12mm
Table stroke 495mm

Working area

Distance between spindle axis and column 130mm
Distance between spindle end and surface of worktable 360mm

Headstock

Spindle speed steps ranges 5pcs
Spindle speeds range 450rpm — 3500rpm
Spindle taper MT2
Travel of spindle quill 65mm

Base

Base size 200mm x 240mm
T-slots 2pcs / 12mm / 80mm

Engines and power supply

Spindle motor power 0.55kW
Voltage 400V / 50Hz / Three phase

Overall dimensions and weight

Weight 55kg
Overall length 556mm
Overall width 370mm
Overall height 850mm

Комплектация

Backwater filtration device
Coolant cooling system
Drilling chuck
Drilling vice
Drilling vice
Reduction sleeve
