TOPTECH

Vertical drilling machine B34H

Серия: B Pro

Max. drilling diameter 34mm

Working table size 426mm x 400mm

Spindle speeds range 145rpm — 4800rpm

Spindle taper MT4

Travel of spindle quill 160mm

Цена и условия

139 407 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine

CNC Absence

Design drilling machine

Capability

Max. drilling diameter 34mm

Working table

Working table size 426mm x 400mm

T-slots 14mm

Table stroke 790mm

Working area

Distance between spindle axis and column 285mm

Distance between spindle end and surface of worktable 790mm

Headstock

Spindle speed steps ranges 9pcs

Spindle speeds range 145rpm — 4800rpm

Spindle feeds 2pcs

Spindle taper MT4

Travel of spindle quill 160mm

Base

Base size 370mm x 390mm

T-slots 2pcs / 14mm / 150mm

Engines and power supply

Spindle motor power 2.2kW

Voltage 400V / Three phase / DC

Overall dimensions and weight

Weight 260kg

Overall length 918mm

Overall width 585mm

Overall height 1895mm

Комплектация

Backwater filtration device

Coolant cooling system

Drilling chuck

MT3

Drilling vice

Reduction sleeve

MT3

Twist drill bit set
