Machine tools and equipment / Metalworking machine tools / Drilling machines / Vertical drilling machines / Vertical drilling machine B24H
TOPTECH

Vertical drilling machine B24H

Серия: B Pro
Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine
Max. drilling diameter 24mm
Working table size 280mm x 300mm
Distance between spindle axis and column 165mm
Distance between spindle end and surface of worktable 445mm
Spindle speeds range 350rpm — 4000rpm
Spindle taper MT2
Travel of spindle quill 85mm
Spindle motor power 0.85kW / 50Hz

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine

Capability

Max. drilling diameter 24mm

Working table

Working table size 280mm x 300mm
T-slots 14mm
Table stroke 595mm

Working area

Distance between spindle axis and column 165mm
Distance between spindle end and surface of worktable 445mm

Headstock

Spindle speed steps ranges 7pcs
Spindle speeds range 350rpm — 4000rpm
Spindle taper MT2
Travel of spindle quill 85mm

Base

Base size 280mm x 260mm
T-slots 2pcs / 14mm / 120mm

Engines and power supply

Spindle motor power 0.85kW / 50Hz
Voltage 400V / Three phase

Overall dimensions and weight

Weight 92kg
Overall length 665mm
Overall width 435mm
Overall height 1000mm

Комплектация

Coolant cooling system
Drilling chuck
MT3
Drilling vice
Drilling vice
Reduction sleeve
MT3
Twist drill bit set
13mm
