Machine tools and equipment / Metalworking machine tools / Drilling machines / Vertical drilling machines / Vertical drilling machine Z5035A
WEIDA

Vertical drilling machine Z5035A

Серия: Z50
Vertical drilling machine variation Round column vertical drilling machine
Max. drilling diameter 35mm
Distance between spindle end and surface of worktable 610mm
Spindle speeds range 70rpm — 2600rpm
Travel of spindle quill 150mm

Цена и условия

637 428 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine
Design drilling machine

Capability

Max. drilling diameter 35mm
Tapping capacity M20

Working table

Working table size 424mm x 424mm
T-slots 2pcs / 14mm

Working area

Diameter of column 140mm
Distance between spindle axis and column 330mm
Distance between spindle end and working surface of basic plate 1150mm
Distance between spindle end and surface of worktable 610mm

Headstock

Spindle speed steps ranges 12pcs
Spindle speeds range 70rpm — 2600rpm
Spindle feeds 3pcs
Range of spindle feeds 0.1mm/r — 0.3mm/r
Spindle taper MT4
Travel of spindle quill 150mm

Base

Base size 420mm x 380mm
T-slots 2pcs / 16mm

Engines and power supply

Spindle motor power 1.5kW / 2.2kW
Cooling pump motor power 0.09kW
Voltage 380V / 50Hz / Three phase

Overall dimensions and weight

Weight 670kg

Периферия

Dividing heads

FW11160A weida
FW11160A weida
Tilting angle of the spindle : 95° / 5° , Center height : 160mm , Gearing ratio : 1:40

Rotary tables

Rotary table TSL250
Rotary table TSL250
Table diameter : 250mm

Комплектация

Drilling chuck
Drilling vice
