WEIDA

Vertical drilling machine Z5050A

Серия: Z50

Vertical drilling machine variation Round column vertical drilling machine

Max. drilling diameter 50mm

Distance between spindle end and surface of worktable 600mm

Spindle speeds range 42rpm — 1865rpm

Travel of spindle quill 180mm

Цена и условия

755 155 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine

Capability

Max. drilling diameter 50mm

Tapping capacity M24

Working table

Working table size 370mm x 500mm

T-slots 2pcs / 14mm

Working area

Distance between spindle axis and column 360mm

Distance between spindle end and working surface of basic plate 1205mm

Distance between spindle end and surface of worktable 600mm

Headstock

Spindle speed steps ranges 12pcs

Spindle speeds range 42rpm — 1865rpm

Spindle feeds 4pcs

Range of spindle feeds 0.07mm/r — 0.4mm/r

Spindle taper MT4

Travel of spindle quill 180mm

Base

Base size 460mm x 450mm

T-slots 2pcs / 16mm

Engines and power supply

Spindle motor power 2.2kW / 2.8kW

Voltage 380V / 50Hz / Three phase

Overall dimensions and weight

Weight 800kg

Комплектация

Drift

Drilling chuck

13mm

Fastening bolts

Reduction sleeve

MT4

Tools box
