WEIDA

Vertical drilling machine Z5040A

Серия: Z50

Vertical drilling machine variation Round column vertical drilling machine

Max. drilling diameter 40mm

Distance between spindle end and surface of worktable 600mm

Spindle speeds range 42rpm — 2050rpm

Travel of spindle quill 180mm

Цена и условия

729 981 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine

Design drilling machine

Capability

Max. drilling diameter 40mm

Tapping capacity M24

Working table

Working table size 370mm x 500mm

T-slots 2pcs / 14mm

Working area

Diameter of column 160mm

Distance between spindle axis and column 360mm

Distance between spindle end and working surface of basic plate 1215mm

Distance between spindle end and surface of worktable 600mm

Headstock

Spindle speed steps ranges 12pcs

Spindle speeds range 42rpm — 2050rpm

Spindle feeds 4pcs

Range of spindle feeds 0.07mm/r — 0.4mm/r

Spindle taper MT4

Travel of spindle quill 180mm

Base

Base size 460mm x 450mm

T-slots 2pcs / 16mm

Engines and power supply

Spindle motor power 2.2kW / 2.8kW

Voltage 380V / 50Hz / Three phase

Overall dimensions and weight

Weight 740kg

Периферия

Rotary tables

Rotary table TSL250

Table diameter : 250mm

Dividing heads

FW11160A weida

Tilting angle of the spindle : 95° / 5° , Center height : 160mm , Gearing ratio : 1:40

Комплектация

Drilling chuck
