Machine tools and equipment / Bending and forming machinery / Wire forming machinery / Hot coiling spring machines / CNC hot-coiling spring machine HCM-35K
KDE

CNC hot-coiling spring machine HCM-35K

Серия: SJX
Control method CNC
Quantity of controlled axis 4pcs
Direction of coiling Right + Left
Wire diameter 15mm — 35mm
Spring diameter 70mm — 270mm
Spring lenght 100mm — 600mm

Цена и условия

12 813 775 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Indication and control

Control method CNC
Quantity of controlled axis 4pcs
Type of spring Compression

Processing parameters

Direction of coiling Right + Left
Wire diameter 15mm — 35mm
Spring diameter 70mm — 270mm
Spring lenght 100mm — 600mm
Max. spring weight: 50kg

Engines and power supply

Spindle motor power 20kW / 1pcs
Spindle speeds range 85rpm
Pitch axis motor 1pcs x 3kW
Pump motor power 4kW
Mandrel center bracket telescopic motor power 4pcs x 0.37kW
Total motor power 30kW
Voltage 380V / 50Hz

Other

Air pressure 0.6MPa
Air consumption 0.3m³/min
Tank capacity 150L

Overall dimensions and weight

Weight 4500kg
Overall length 5000mm
Overall width 2800mm
Overall height 2000mm

Товары этой серии

Сравнить товары серии
CNC hot-coiling spring machine
KDE SJX

CNC hot-coiling spring machine HCM-35K

Control method: CNC
Quantity of controlled axis: 4pcs
Direction of coiling: Right + Left
Wire diameter: 15mm — 35mm
Spring diameter: 70mm — 270mm
Spring lenght: 100mm — 600mm
12 813 775 RUB*
Подробнее
CNC hot-coiling spring machine
KDE SJX

CNC hot-coiling spring machine HCM-50K

Control method: CNC
Quantity of controlled axis: 4pcs
Direction of coiling: Right + Left
Wire diameter: 20mm — 50mm
Spring diameter: 100mm — 350mm
Spring lenght: 100mm — 800mm
16 049 140 RUB*
Подробнее
CNC hot-coiling spring machine
KDE SJX

CNC hot-coiling spring machine HCM-65K

Control method: CNC
Quantity of controlled axis: 4pcs
Direction of coiling: Right + Left
Wire diameter: 20mm — 65mm
Spring diameter: 100mm — 480mm
Spring lenght: 100mm — 1200mm
18 424 522 RUB*
Подробнее
CNC hot-coiling spring machine
KDE SJX

CNC hot-coiling spring machine SJX-25

Control method: CNC
Quantity of controlled axis: 2pcs
Direction of coiling: Right + Left
Wire diameter: 10mm — 25mm
Spring diameter: 60mm — 250mm
Spring lenght: 100mm — 600mm
6 204 432 RUB*
Подробнее
CNC hot-coiling spring machine
KDE SJX

CNC hot-coiling spring machine SJX-50

Control method: CNC
Quantity of controlled axis: 2pcs
Direction of coiling: Right + Left
Wire diameter: 20mm — 50mm
Spring diameter: 100mm — 350mm
Spring lenght: 150mm — 800mm
11 680 056 RUB*
Подробнее
CNC hot-coiling spring machine
KDE SJX

CNC hot-coiling spring machine SJX-50B

Control method: CNC
Quantity of controlled axis: 2pcs
Direction of coiling: Right + Left
Wire diameter: 20mm — 50mm
Spring diameter: 80mm — 450mm
Spring lenght: 100mm — 800mm
Цена по запросу
Подробнее
CNC hot-coiling spring machine
KDE SJX

CNC hot-coiling spring machine SJX-65

Control method: CNC
Quantity of controlled axis: 2pcs
Direction of coiling: Right + Left
Wire diameter: 20mm — 65mm
Spring diameter: 100mm — 450mm
Spring lenght: 100mm — 1200mm
Цена по запросу
Подробнее
