Machine tools and equipment / Bending and forming machinery / Wire forming machinery / Hot coiling spring machines / CNC hot-coiling spring machine HCM-50K
KDE

CNC hot-coiling spring machine HCM-50K

Серия: SJX
Control method CNC
Quantity of controlled axis 4pcs
Direction of coiling Right + Left
Wire diameter 20mm — 50mm
Spring diameter 100mm — 350mm
Spring lenght 100mm — 800mm

Цена и условия

16 049 140 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Indication and control

Control method CNC
Quantity of controlled axis 4pcs
Type of spring Compression

Processing parameters

Direction of coiling Right + Left
Wire diameter 20mm — 50mm
Spring diameter 100mm — 350mm
Spring lenght 100mm — 800mm
Max. spring weight: 150kg

Engines and power supply

Spindle motor power 30kW
Spindle speeds range 73rpm
Pitch axis motor 5.5kW
Pump motor power 5.5kW
Mandrel center bracket telescopic motor power 4pcs x 0.55kW
Cooling pump motor power 1.1kW
Total motor power 45kW
Voltage 380V / 50Hz

Other

Air pressure 0.6MPa
Tank capacity 200L

Overall dimensions and weight

Weight 8500kg
Overall length 6000mm
Overall width 3000mm
Overall height 2000mm
