KDE

CNC hot-coiling spring machine SJX-25

Серия: SJX

Control method CNC

Quantity of controlled axis 2pcs

Direction of coiling Right + Left

Wire diameter 10mm — 25mm

Spring diameter 60mm — 250mm

Spring lenght 100mm — 600mm

Цена и условия

6 204 432 RUB*

Условия доставки

ddp Москва

* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Indication and control

Control method CNC

Quantity of controlled axis 2pcs

Type of spring Compression

Processing parameters

Direction of coiling Right + Left

Wire diameter 10mm — 25mm

Spring diameter 60mm — 250mm

Spring lenght 100mm — 600mm

Max. spring weight: 50kg

Engines and power supply

Spindle motor power 15kW / 1pcs

Spindle speeds range 120rpm

Pitch axis motor 1pcs x 3.7kW

Pump motor power 4kW

Mandrel center bracket telescopic motor power 4pcs x 0.37kW

Cooling pump motor power 1.1kW

Total motor power 25kW

Voltage 380V / 50Hz

Other

Air consumption 2m³/min

Working pressure 50bar

Tank capacity 150L

Overall dimensions and weight

Weight 4000kg

Overall length 4200mm

Overall width 1800mm

Overall height 1800mm
