Machine tools and equipment / Plastic processing machinery / Injection molding machines / Hydraulic injection molding machines / Injection Molding Machine PT130
LKIMM

Injection Molding Machine PT130

Серия: POTENZA-III
Machine drive Servo-Hydraulic (Hybrid)
Clamping force 1300kN
Space between tie bars 410mm x 410mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Machine drive Servo-Hydraulic (Hybrid)
Clamping mechanism Toggle system

Injection Unit

Max. rotational speed 230rpm
Screw diameter
35mm
40mm
45mm
Screw ratio
25.7L/D
22.5L/D
20L/D
Theoretical shot volume
192cm³
251cm³
318cm³
Injection pressure
214MPa
164MPa
130MPa
Injection weight
175g
229g
289g
Injection speed
108cm³/s
142cm³/s
180cm³/s

Clamping unit

Clamping force 1300kN
Clamping stroke 360mm
Thickness of mould 150mm / 450mm
Space between tie bars 410mm x 410mm
Ejector stroke 120mm
Ejector force 49kN

Other

Max. pump pressure 17.5MPa
Pump power 13.4kW
Heating power 11.3kW
Oil tank capacity 195L
Hopper capacity 50L

Overall dimensions and weight

Weight 4000kg
Overall length 4590mm
Overall width 1110mm
Overall height 1910mm
