Machine tools and equipment / Plastic processing machinery / Injection molding machines / Hydraulic injection molding machines / Injection Molding Machine PT80
LKIMM

Injection Molding Machine PT80

Серия: POTENZA-III
Machine drive Servo-Hydraulic (Hybrid)
Clamping force 800kN
Space between tie bars 360mm x 360mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Machine drive Servo-Hydraulic (Hybrid)
Clamping mechanism Toggle system

Injection Unit

Max. rotational speed 240rpm
Screw diameter
28mm
30mm
35mm
Screw ratio
25L/D
23L/D
20L/D
Theoretical shot volume
98cm³
113cm³
154cm³
Injection pressure
270MPa
236MPa
173MPa
Injection weight
90g
103g
140g
Injection speed
86cm³/s
99cm³/s
135cm³/s

Clamping unit

Clamping force 800kN
Clamping stroke 320mm
Thickness of mould 150mm / 390mm
Space between tie bars 360mm x 360mm
Ejector stroke 100mm
Ejector force 27kN

Other

Max. pump pressure 17.5MPa
Pump power 13.4kW
Heating power 6.2kW
Oil tank capacity 160L
Hopper capacity 50L

Overall dimensions and weight

Weight 3000kg
Overall length 4150mm
Overall width 1070mm
Overall height 1840mm
