Machine tools and equipment / Plastic processing machinery / Injection molding machines / Hydraulic injection molding machines / Injection Molding Machine PT160
LKIMM

Injection Molding Machine PT160

Серия: POTENZA-III
Machine drive Servo-Hydraulic (Hybrid)
Clamping force 1600kN
Space between tie bars 470mm x 470mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Machine drive Servo-Hydraulic (Hybrid)
Clamping mechanism Toggle system

Injection Unit

Max. rotational speed 220rpm
Screw diameter
40mm
45mm
50mm
Screw ratio
25L/D
22L/D
20L/D
Theoretical shot volume
251cm³
318cm³
393cm³
Injection pressure
228MPa
180MPa
146MPa
Injection weight
229g
289g
356g
Injection speed
153cm³/s
194cm³/s
239cm³/s

Clamping unit

Clamping force 1600kN
Clamping stroke 430mm
Thickness of mould 180mm / 520mm
Space between tie bars 470mm x 470mm
Ejector stroke 140mm
Ejector force 49kN

Other

Max. pump pressure 17.5MPa
Pump power 20.5kW
Heating power 11.9kW
Oil tank capacity 240L
Hopper capacity 50L

Overall dimensions and weight

Weight 5000kg
Overall length 5080mm
Overall width 1250mm
Overall height 1900mm
