Machine tools and equipment / Plastic processing machinery / Injection molding machines / Hydraulic injection molding machines / Injection Molding Machine PT250
LKIMM

Injection Molding Machine PT250

Серия: POTENZA-III
Machine drive Servo-Hydraulic (Hybrid)
Clamping force 2500kN
Space between tie bars 610mm x 570mm

Цена и условия

Цена по запросу

Характеристики

Basic feauturies

Machine drive Servo-Hydraulic (Hybrid)
Clamping mechanism Toggle system

Injection Unit

Max. rotational speed 200rpm
Screw diameter
50mm
55mm
60mm
Screw ratio
24L/D
22L/D
20L/D
Theoretical shot volume
520cm³
629cm³
749cm³
Injection pressure
219MPa
181MPa
152MPa
Injection weight
473g
572g
681g
Injection speed
266cm³/s
322cm³/s
383cm³/s

Clamping unit

Clamping force 2500kN
Clamping stroke 540mm
Thickness of mould 200mm / 580mm
Space between tie bars 610mm x 570mm
Ejector stroke 150mm
Ejector force 77kN

Other

Max. pump pressure 17.5MPa
Pump power 35.6kW
Heating power 20.6kW
Oil tank capacity 400L
Hopper capacity 60L

Overall dimensions and weight

Weight 6000kg
Overall length 6290mm
Overall width 1610mm
Overall height 2330mm
