Machine tools and equipment / Bending and forming machinery / Wire forming machinery / Spring coiling machines / 7-axis CNC spring coiling machine TK-760
WNJ

7-axis CNC spring coiling machine TK-760

Серия: TK
Quantity of controlled axis 7pcs
Spring diameter 80mm
Wire diameter 2mm — 6mm
Loading weight 1000kg

Цена и условия

5 895 432 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Quantity of controlled axis 7pcs

CNC

Spring coiling machine computer Windows based
CNC language Chinese / English

Processing parameters

Spring diameter 80mm
Wire diameter 2mm — 6mm
Wire feeding speed 95m/min
Direction of coiling Right + Left

Wire feeder

Loading weight 1000kg
Diameter of feeding tray 2200mm
Motor power 2.2kW

Controlled axes

OD control axis 2.7kW / 2.7kW
Pitch axis 2kW
Wire feed axis 15kW
Core axis 1kW
Cutting axis 5.5kW / 5.5kW

Engines and power supply

Voltage 380V / 50Hz
Total motor power 36kW

Overall dimensions and weight

Weight 4020kg
Overall length 2350mm
Overall width 2300mm
Overall height 2065mm

Периферия

Wire feeders

SLB-1000
SLB-1000
Diameter of feeding tray : 2200mm , Loading weight : 1000kg , Motor power : 2.2kW

Spring length detector

Spring videocamera (WNJ)
Spring videocamera (WNJ)

Spring lenght sorting device

Spring length sorting device (WNJ)
Spring length sorting device (WNJ)

Комплектация

Infrared probe
Left-direction coiling knife rest
Probe
Right-direction coiling knife rest
Tools box
Автоматическая смазка направляющих
Инструмент и оснастка для навивки
Количество: 1 set
Лампа освещения рабочей зоны
