Machine tools and equipment / Bending and forming machinery / Wire forming machinery / Spring coiling machines / 9-axis CNC spring coiling machine TK-14230
WNJ

9-axis CNC spring coiling machine TK-14230

Серия: TK
Quantity of controlled axis 9pcs
Type of spring Compression
Spring diameter 260mm
Wire diameter 12mm — 23mm
Direction of coiling Right + Left

Цена и условия

33 534 726 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Quantity of controlled axis 9pcs
Type of spring Compression

CNC

Spring coiling machine computer Windows based

Processing parameters

Spring diameter 260mm
Wire diameter 12mm — 23mm
Wire feeding speed 65m/min
Direction of coiling Right + Left

Controlled axes

OD control axis 8.8kW / 8.8kW
Pitch axis 22kW
Wire feed axis 6pcs x 22kW
Cutting axis 56kW / 56kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC
Total motor power 336kW

Overall dimensions and weight

Weight 31000kg
Overall length 6850mm
Overall width 4000mm
Overall height 3050mm

Периферия

Wire feeders

SLB-2800
SLB-2800

Spring lenght sorting device

Spring length sorting device (WNJ)
Spring length sorting device (WNJ)

Spring length detector

Spring videocamera (WNJ)
Spring videocamera (WNJ)

Комплектация

Infrared probe
Oil gun
Probe
Tools box
Автоматическая смазка направляющих
Инструмент и оснастка для навивки
Количество: 1 set
Лампа освещения рабочей зоны
