Machine tools and equipment / Bending and forming machinery / Wire forming machinery / Spring coiling machines / 7-axis CNC spring coiling machine TK-890
WNJ

7-axis CNC spring coiling machine TK-890

Серия: TK
Quantity of controlled axis 7pcs
Type of spring Compression
Spring diameter 120mm
Wire diameter 3mm — 9mm

Цена и условия

9 411 168 RUB*
Условия доставки
ddp Москва
* Цена рассчитана на основе конфигурации оборудования, периферии, комплектации и города доставки — Москва. Стоимость товара и условия продажи не являются публичной офертой.

Характеристики

Basic feauturies

Quantity of controlled axis 7pcs
Type of spring Compression

CNC

Spring coiling machine computer Windows based
CNC language Chinese / English

Processing parameters

Spring diameter 120mm
Wire diameter 3mm — 9mm
Wire feeding speed 105m/min
Direction of coiling Right + Left

Controlled axes

OD control axis 7kW / 7kW
Arbor moving axis 1.5kW
Pitch axis 2.7kW
Wire feed axis 2pcs x 28.3kW
Cutting axis 18.2kW / 18.2kW

Engines and power supply

Voltage 380V / 50Hz / Three phase / AC
Total motor power 113kW

Overall dimensions and weight

Weight 4020kg
Overall length 2350mm
Overall width 2300mm
Overall height 2065mm

Периферия

Wire feeders

SLB-1000
SLB-1000
Diameter of feeding tray : 2200mm , Loading weight : 1000kg , Motor power : 2.2kW

Spring length detector

Spring videocamera (WNJ)
Spring videocamera (WNJ)
Length detector (WNJ)
Length detector (WNJ)

Spring lenght sorting device

Spring length sorting device (WNJ)
Spring length sorting device (WNJ)

Комплектация

Infrared probe
Left-direction coiling knife rest
Probe
Right-direction coiling knife rest
Tools box
Количество: 1 pcs
Автоматическая смазка направляющих
Инструмент и оснастка для навивки
Количество: 1 set
Лампа освещения рабочей зоны
Количество: 1 pcs
